Product description
Create beautiful, professional 3D digital spaces
- Captivating, high-resolution, photorealistic digital twins
- Extended scanning range up to 100 m for fast capture of large spaces (*Standard range 20 m, extended range only available in e57 files)
- Impressive scanning and imaging capabilities indoors and outdoors, even in direct sunlight!
Unbelievable accuracy and resolution
- Ultra-fast, high-precision lidar sensor performs millions of measurements per scan
- High precision rendering of large projects (+/- 20mm @10m) and high precision digital twin generation (100K points per second).
- Performs each scan in <20 seconds
- Removable, rechargeable battery allows continuous scanning up to all day.
Technical specification
General
- Dimensions: 181mm x 161.4mm x 76mm
- Weight: 2.2kg
- Battery: >220 scans continuously, assuming consecutive scans
- Battery charge time: 2.5 hours at 80% charge, 3.5 hours at 100% charge
- Mounting mechanism: quick-release tripod clamp; 3/8-16 internal thread
- GPS: Includes
- Operating temperature: 0°C to 40°C
- Storage temperature: -20°C to 60°C
- Ingress protection: IP43
Scanning
- Depth technology: LiDAR
- Laser: Class 1 (according to IEC 60825-1:2014)
- Wavelength: 904 nm
- Field of view: 360° H / 295° V
- Accuracy: +/- 20mm @ 10m
- Depth resolution: 100k points per second, 1.5M points/scan
- Minimum operating range: 0.5m
- Maximum operating range: Up to 100m (E57 only)
- 3D data registration: Automatic
Imaging
- Imaging
Output pano pixels: 134.2MP
- Number of exposures per HDR frame: 5
- White balance: automatic, full model
System
- Capture speed: <20 seconds/scan
- Camera startup time: <40 seconds
- Remote operation: Matterport Capture app on Apple or Android mobile devices
- Wireless communication: BLE for Wi-Fi connection setup, WiFi 802.11 5GHz communication with mobile device running Capture App
